CHARACTERIZATION

- solar collector pump control
- low cost utilisation of solar energy for warm air heating by gain heat from loft spaces, warm air collectors, roof glazing places
- two sensor-signals evaluation (thermistors, light-dependent resistors, resistance transducer,capacity transducer etc.)
- possibility to place in any area till ZONE 1 (according to type of sensor)
- possibility to adjust the level of blocking function
- indicator LED for power,relay status,blocking function (interruption of loop,short-circuit of loop)
- output relay (two-way contact)
- possibility to change the direction of switching
- 35mm rail mounting ( EN 50 022, DIN 46277/3)
- approved according to ČSN EN 61010-1 -Declaration of conformity
- set include 2 temperature sensors

TECHNICAL PARAMETERS

Supply voltage

230 V / 50 Hz
